Discussion Starter · #1 ·
I need to replace this engine cover so i've been searching online, looking at bike schematics and all but i can't seem to find this part, or even the name of it. In the pic below, whats the proper name for the engine cover to the immediate right of the sprocket cover? 07. ZX-6R



· Registered
Joined
·
887 Posts
that would be part number 14032 - cover-clutch $177.57 at your local kawasaki dealership

also make sure to replace gasket 11061c $18.44

but thats the cover missing from the picture, but to the right of the sprocket cover? or do you mean the right of the gear cover, smaller black one? then that would be part number 14091 - Cover-Starter
